Important
*1 Coat Low Lustre Alkyd Oil must be top coated within 30 days.
Clear Cedar Boards
Western Red Cedar – Kiln Dried, Surfaced Four Sides (S4S), Eased Edge
| NOMINAL SIZE | ACTUAL SIZE | Surfacing |
|---|---|---|
|
1 x 4
|
11/16″ x 3-1/2″ |
S4S
|
|
1 x 6
|
11/16″ x 5-1/2″ |
S4S
|
|
1 x 8
|
11/16″ x 7-1/4″ |
S4S
|
|
1 x 10
|
11/16″ x 9-1/4″ |
S4S
|
|
1 x 12
|
11/16″ x 11-1/4″ |
S4S
|
Western Red Cedar – Kiln Dried, Surfaced Four Sides (S4S), Eased Edge
| NOMINAL SIZE | ACTUAL SIZE | Surfacing |
|---|---|---|
|
2 x 4
|
1-1/2″ x 3-1/2″
|
S4S |
|
2 x 6
|
1-1/2″ x 5-1/2″ |
S4S |
|
2 x 8
|
1-1/2″ x 7-1/4″ |
S4S |
|
2 x 12
|
1-1/2″ x 11-1/4″ |
S4S |
Western Red Cedar – Kiln Dried, Surfaced Four Sides (S4S), Eased Edge
| NOMINAL SIZE | ACTUAL SIZE | Surfacing |
|---|---|---|
|
5/4 x 4
|
1″ x 3-1/2″ |
S4S
|
|
5/4 x 6
|
1″ x 5-1/2″ |
S4S |
|
5/4 x 8
|
1″ x 7-1/4″ |
S4S |
|
5/4 x 10
|
1″ x 9-1/4″ |
S4S |
|
5/4 x 12
|
1″ x 11-1/4″ |
S4S |
Western Red Cedar – Kiln Dried, Surfaced One Side Two Edges (S1S2E), Square Edge
| NOMINAL SIZE | ACTUAL SIZE | Surfacing |
|---|---|---|
|
1 x 4
|
11/16″ x 3-1/2″ |
S1S2E
|
|
1 x 6
|
11/16″ x 5-1/2″ |
S1S2E
|
|
1 x 8
|
11/16″ x 7-1/4″ |
S1S2E
|
|
1 x 10
|
11/16″ x 9-1/4″ |
S1S2E
|
|
1 x 12
|
11/16″ x 11-1/4″ |
S1S2E |
Western Red Cedar – Kiln Dried, Surfaced One Side Two Edges (S1S2E), Square Edge
| NOMINAL SIZE | ACTUAL SIZE | Surfacing |
|---|---|---|
|
5/4 x 4
|
1″ x 3-1/2″ |
S1S2E
|
|
5/4 x 6
|
1″ x 5-1/2″ |
S1S2E
|
|
5/4 x 8
|
1″ x 7-1/4″ |
S1S2E
|
|
5/4 x 10
|
1″ x 9-1/4″ |
S1S2E
|
|
5/4 x 12
|
1″ x 11-1/4″ |
S1S2E
|
Western Red Cedar – Kiln Dried, Surfaced One Side Two Edges (S1S2E), Square Edge
| NOMINAL SIZE | ACTUAL SIZE | Surfacing |
|---|---|---|
|
2 x 4
|
1-1/2″ x 3-1/2″ |
S1S2E
|
|
2 x 6
|
1-1/2″ x 5-1/2″ |
S1S2E
|
|
2 x 8
|
1-1/2″ x 7-1/4″ |
S1S2E
|
|
2 x 12
|
1-1/2″ x 11-1/4″ |
S1S2E
|
Western Red Cedar, Kiln Dried, Surfaced on 4 Sides (S4S)
| NOMINAL SIZE | ACTUAL SIZE |
|---|---|
|
5/4 x 6
|
1″ x 5-1/2″
|
Clear Cedar Paneling
Western Red Cedar – Kiln Dried, Reversible
| NOMINAL SIZE | ACTUAL SIZE | Surfacing | EXPOSURE | |
|---|---|---|---|---|
|
1 x 4
|
11/16″ x 3-1/2″ |
Resawn Rough or Smooth
|
400/lf per Square @ 3″ Exposure
|
|
 |
||||
 |
||||
|
1 x 6
|
11/16″ x 5-1/2″ |
Resawn Rough or Smooth
|
240/lf per Square @ 5″ Exposure
|
|
Western Red Cedar – Kiln Dried
| NOMINAL SIZE | ACTUAL SIZE | EXPOSURE |
|---|---|---|
|
1 x 4
|
5/8″ x 3-1/2″
|
400/lf per Square @ 3″ Exposure
|
Douglas Fir
| NOMINAL SIZE | ACTUAL SIZE | EXPOSURE |
|---|---|---|
|
1 x 4
|
5/8″ x 3-1/2″
|
400/lf per Square @ 3″ Exposure
|
Bevel Siding
Vertical Grain Sidings are considered by industry experts as the best of the best. Consisting of entirely heartwood, they are more stable, offer the best coating adhesion, are 100% usable, and have no raised grain. They are available as reversible smooth faces or resawn faces.
Western Red Cedar – Kiln Dried, Reversible
| NOMINAL SIZE | ACTUAL SIZE | Surfacing | EXPOSURE |
|---|---|---|---|
|
1/2 x 4
|
1/2″ x 3-1/2″ |
Resawn Rough or Smooth Face
|
480/lf per Square @ 2-1/2″ Exposure
|
|
1/2 x 6
|
1/2″ x 5-1/4″ |
Resawn Rough or Smooth Face
|
300/lf per Square @ 4″ Exposure
|
|
1/2 x 8
|
1/2″ x 7-1/4″ |
Resawn Rough or Smooth Face
|
200/lf per Square @ 6″ Exposure
|
|
3/4 x 10
|
3/4″ x 9-1/4″ |
Resawn Rough or Smooth Face
|
150/lf per Square @ 8″ Exposure
|
Western Red Cedar – Kiln Dried, Surfaced Four Sides (S4S)
| NOMINAL SIZE | ACTUAL SIZE | Surfacing | EXPOSURE |
|---|---|---|---|
|
1/2 x 4
|
1/2″ x 3-1/2″
|
Resawn Rough or Smooth
|
480/lf per Square @ 2-1/2″ Exposure
|
|
1/2 x 6
|
1/2″ x 5-1/4″
|
Resawn Rough or Smooth
|
300/lf per Square @ 4″ Exposure
|
|
1/2 x 8
|
1/2″ x 7-1/4″
|
Resawn Rough or Smooth
|
200/lf per Square @ 6″ Exposure
|
|
3/4 x 10
|
3/4″ x 9-1/4″
|
Resawn Rough or Smooth
|
150/lf per Square @ 8″ Exposure
|
